The Liteforce has been designed by combining different design elements from the Ozone wing range in a strong but lightweight design to deliver easy and very effective performance in lightwinds.
Find a dealerAvailable in two, powerful sizes of 6.6m and 7.7m, both are packed with low end grunt to allow for super early planing, while the low drag handling also allows for remarkable levels of comfort at the top end of the wing’s range.
The carefully developed compact planform means that the tips are less likely to catch the water during manoeuvres, allowing for maximum freeride fun, however light the conditions.
Allowing for excellent aerodynamic performance with a longer lasting shape, the proven supportive structure of the 125g performance dacron on the leading edge and strut helps the Liteforce manage wind speeds beyond the limits these big wings would otherwise have.
Using a performance dacron material that is rigid and strong has allowed our designers to pre-load the leading edge so that its shape will have far less deformation under load. Giving you the confidence to session during periods that the wind may pick up, knowing you will still be able to hold on with more comfort and control.
While both Liteforce wings have a large overall area, they are specifically designed with a compact planform to make handling and manoeuvring as easy as possible. Here’s some basic guidance to help you choose the right size:
Riders of this height will have no problem handling either the 6.6 or 7.7m. Their choice will be dictated by how important the extra pure low end power of the 7.7m will be; either enabling them to ride in the absolute lightest possible winds, or to give them more of an advantage if they’re a particularly heavy rider.
We’d recommend the 6.6m. As well as being easier to handle, it will provide more than enough power.
The optimised sail shaping and horizontal panels mean that each seam, from strut to tip, creates a stronger line connection in the sail, distributing the load better along the warp of the fabric, reducing canopy stretch over time.
The ergonomic carbon fibre handles with EVA grip provide a super-direct connection for more control in all situations. They also ensure you get every ounce of power from each pump of the wing!
The combination of all these features contribute to the Liteforce’s light and agile feeling and unbeatable range.
Two carefully positioned windows running parallel with the chord of the wing on either side of the strut allow you to get a sense of other water users downwind of you while holding the wing at a normal riding angle.
(The windows on the Flow wing are span oriented instead, because riders have more space above the water to move the wing up and down as well as back and forth when using the windows, so a narrower but taller window is best for that wing to offer good visual opportunities at different angles).
The Liteforce windows are sized to offer some visual assistance without considerably impacting the weight, and therefore performance of the wing. We advise riders of any wings to always remain attentive to your surroundings, especially when going for a change in direction. We always recommend to lift the wing overhead to get a totally clear view of the water downwind before making a manoeuvre.
Combined with cutting edge manufacturing and the highly skilled craftspeople who apply their experience in our own factory, the Liteforce is born light but genetically strong.
We avoid adding surplus features or unnecessary cosmetic items to our designs and only use top of the line materials put through a rigorous testing programme. To be as efficient in flight as possible we have always believed in designing lightness combined with strength in our paragliders, kites and now wings.
Using a performance dacron material that is rigid and strong has allowed our designers to pre-load the leading edge so that its shape will have far less deformation under load. Giving you the confidence to session during periods that the wind may pick up, knowing you will still be able to hold on with more comfort and control.
The Liteforce is for riders who want to score the most riding time possible with the least amount of complication. When you’re able to hit the water in the lightest of winds and hold on for longer, you’ll add many more riding hours to your season while also enjoying the impressive handling agility for such large wings.
Other big wings in the Ozone range include the Fly and the Flux. Here are some comparisons to help you choose the right model for you:
The Liteforce is quite similar in profile and shape to the Fly, but is:
The future is now. All Ozone kite and wings are designed with our own highly advanced custom built CAD software that we control and modify with each new product design. Allowing for specifically tailored technical developments, our designers can maximise performance while also minimising waste.
Ozone uniquely owns its own factory where all kites, wings, boards, hydrofoils, paragliders, speed wings and accessories are made. Guaranteeing hand checked quality control and the finest materials at every step, there are also excellent working conditions for all 1000 employees.
The De-Power/Surf Handle at the front of the Leading Edge offers increased control when flying the wing single-handed and features a soft knuckle padding for extra comfort.
Fast Flow Air Valves on both the Leading Edge and Strut makes inflation, deflation and packing a breeze.
Ergonomically angled front and back carbon fibre handles with EVA grip provide maximum control and comfort with incredible feel and response. The front handle mount features a soft bumper to protect your head and board during water starts.
Our Direct Connect construction method improves load distribution between the Leading Edge, Strut and Canopy. The Strut is connected directly to the Leading Edge with internal and external reinforcements. This unique construction method ensures clean profiles are maintained with the optimum canopy tension.
What’s on the inside counts too – internal reinforcements for improved strength and durability; such as a Double layered Dacron + Insignia taped Leading Edge closing seam with high strength threads.
Overlap flat seam construction improves sail control resulting in an overall cleaner canopy.
The Leading Edge and Struts are reinforced in high stress areas to ensure the kite canopy remains in shape and performs at its best.
Horizontal canopy panels and adjoining seams optimise load distribution through warp and weft of the material, improving feeling and reducing material stretch.
Trailing Edge reinforcement with an internal lightweight Dyneema line reduces canopy wear and helps to maintain optimum Trailing Edge tension as designed.
Leading Edge bumpers are often large and unnecessary cosmetic items. At Ozone we build our kites and wings for performance and durability using the best materials & components available. Any areas requiring scuff protection we use a lightweight durable material with superior abrasion resistance, while keeping a low profile in order to reduce drag and maintain performance.
Rigid Battens strategically positioned along the Trailing Edge improve canopy tension and reduce flutter - enhancing performance, feedback to the rider and reducing canopy material wear.
Easy view windows on either side of the strut provide safety for you and others around.
Our bladders are constructed in-house with advanced custom built welding machines. Double layered sections are applied to any potential wear areas.
A harness line can be attached around the handle mounts or tube for customised rider preference.
The Swivel Leash Line features a strong Dyneema line with internal bungee core and an ultra light Stainless Steel swivel to keep the leash twist free. It connects to the wings Leading Edge via a loop-to-loop connection and can easily be removed if necessary.
The Waist Strap is slim and lightweight with a strong buckle closure and size adjustment buckle. It connects to the Leash Line via a loop-to-loop connection. If you become overpowered or lose control let go of the wing and it will de-power on the Leash Line. Our wings ship standard with a Waist Strap pre-attached to the Leash Line.
Quick and easy to install, our Wing Harness Line is a slim and lightweight design with an internal bungee contracting when unhooked to stay out of the way.
The easy to use Quick Release is for riders who prefer extra security to detach from the wing in a fast and easy way. It is compatible with the Wing Waist Leash or a harness. The Wing Quick Release is sold separately.
The Wrist Strap features a velcro closure with a soft neoprene inside layer. It connects to the Leash Line via a loop-to-loop connection, If you become overpowered or lose control let go of the wing and it will de-power on the leash line. The Wrist Strap is sold separately.
- Lightweight with loads of space
- Internal stash pocket
- External pump holder
- Adjustable shoulder straps with double layer padding for carrying a board and foil over the shoulder
- Back panel foam padding provides extra comfort
At Ozone we are passionate about sports, and it is this passion that drives our design team to perfect and develop products that we love to ride with. We are proud of the quality of our products, and are constantly searching for the best components and materials to use in our designs. We manufacture in our own high-quality production facility in Vietnam, which guarantees a build quality that we are proud to put the Ozone name on. A close look at one of our products reveals that same superior quality and construction that ensures that every Ozone product will enjoy a long life, with consistent performance and aesthetics. To view the factory video visit our website www.flyozone.com. Many dynamic action sports carry inherent risks but with common sense and education from qualified instructors means you can easily enjoy these incredible sports. Accidents generally happen due to a lack of experience, changing weather conditions or from using equipment not suited to the riders’ ability and/or conditions. Always take the time to learn safely with qualified instruction and you will progress far quicker. Ride safe Team Ozone
By assembling and/or using this Ozone product, you agree that you have read and understood the entire Ozone product owners manual, including all instructions and warnings contained in that manual, prior to using the Ozone product in any way. You additionally agree that you will ensure any additional or subsequent user of your Ozone product will read and understand the entire Ozone product owners manual, including all instructions and warnings contained in that manual, prior to allowing that person to use your Ozone product.
Use of the Ozone product and any of its components involve certain risks, dangers, and hazards which can result in serious personal injury and death to both the user and to non-user third parties. In using this Ozone product, you freely agree to assume and accept any and all known and unknown risks of injury to you and third parties while using this equipment. The risks inherent in this sport can be greatly reduced by abiding by the warning guidelines listed in this owner manual and by using common sense.
In consideration of the sale of the Ozone product to you, you herby agree to the fullest extent permitted by law, as follows;
TO WAIVE ANY AND ALL CLAIMS that you have or may in the future have against Ozone Kitesurf LTD or Ozone Kites LTD and all related parties resulting from use of the Ozone product and any of its components.
TO RELEASE Ozone Kitesurf LTD or Ozone Kites LTD and all related parties from any and all liability for any loss, damage, injury or expense that you or any users of you Ozone product may suffer, or that your next of kin may suffer, as a result of the use of the Ozone product, due to any cause whatsoever, including negligence or breach of contract on the part of Ozone Kitesurf LTD or Ozone Kites LTD and all related parties in the design or manufacture of the Ozone product and any of its components.
In the event of your death or incapacity, all provisions contained herein shall be effective and binding upon your heirs, next of kin, executors, administrators, assigns, and representatives. Ozone Kitesurf LTD or Ozone Kites LTD related parties have not made and expressly deny and oral or written representations other than what is set forth herein and the Ozone product owners manual.
Always use extreme caution when using this product.
Misuse of this product can cause serious injury or death.
Only use this product if you are in good physical health.
Never act in a careless manner when using this product (such as jumping in the air, or tying yourself down).
You are responsible for your own safety, and the safety of others around you when using this product.
If you are under 18 you should have your parents or legal guardian read these warnings and instructions. You should not use this product unless you are under proper guidance and supervision.
The use of this product exposes the user to many unavoidable and unexpected risks, dangers and hazards.
Do not use this product if you are under the influence of alcohol, drugs or medications.
Before using this product you must take lessons from a certified instructor/school.
Always wear a helmet when using this product.
This product is not a personal flotation device. Always wear a Coast Guard approved personal flotation device when using this product near the water.
Always carefully inspect all of your equipment before using it.
Never allow anyone who is not familiar with this product to use it without experienced assistance.
This product is equipped with user operated release systems, which need to be activated by the user to work.
The leash system is not a permanent attachment to this product. Never permanently attach yourself to the product or any of its components.
This manual refers to the current product it comes with. No information contained herein applies to previous and/or other products. Always read and understand all warnings and instructions for any other product being used. To view previous product manuals go to www.flyozone.com
Always use the Leash. Attach it before you start.
NOTE:
If packing on the water, after rolling the wing up, screw the valves back in to seal the bladders to avoid water entering.
This is a technical product used in harsh outdoor environments.
Use common sense and care for your equipment.
•Never inflate this product on a rough surface.
•Inflate slowly and ensure the bladders are inflating correctly. If you see a twist or something looks strange stop pumping immediately and check bladders. They may need re-inserting to ensure they inflate properly.
•Once you have inflated secure the product. Do not use heavy objects. Boards and fins can damage the material.
•Never leave this product un-used for long periods of time in the sun and wind. UV, canopy flapping due to wind, sand etc hitting the sailcloth can all severely shorten the products lifespan.
•Never pack this product wet, only when completely dry. Packing wet can damage the material and its coatings and may lead to dye running. This is not valid for warranty.
•Never leave this product inside a car or in direct sunlight.
We supply a repair kit with the following contents:
1. A4 pieces of sail cloth
2. A4 piece of Dacron
3. 1 x length of 50mm wide sticky black repair tape
4. 6” x 3” Tear-Aid bladder repair patch
5. 2 Alcohol wipes
If you have a major repair like a tear across panels, struts or the leading edge take the kite to your local sail repair shop. For minor tears and bladder punctures you can easily fix these yourself with the repair kit supplied with the kite.
We can make any combination of colours using the colour chooser below. The manufacturing time for these special kites is 30 days. Design your kite, share with your friends and ask your dealer to place your order.
Millions of people go to the beach every year and kitesurfing is the most visually spectacular beach sport around, drawing the eyes of attention from everyone. Kites are huge and kites with a customized design can be amazing advertising spaces.
Flying up and down the beach, park or snow all day long, these spaces can be used to advertise local and international businesses, kite-schools or simply for your own kite with a design that suits you perfectly and makes you stand out a little more from the crowd. If you have your own company you can add your company logo to your kites which allows them to be written off as a business operating expense. How cool is that!
For mainstream companies the opportunity to invest in a flying Billboard is obvious at a fraction of the cost to normal advertising. So far we have worked with many of the World’s leading brands making them kites or making kites for riders sponsored by mainstream brands that see the benefit in Kite sports.
Check out some of the custom kite designs we’ve made for customers: custom kite gallery
Quotes vary depending on the complexity and size of the logo or design. We can only give a quote once we have the info (see above)
For logos to be stuck onto only 1-2 kites, we print the logo onto the white rip-stop sticky-back material. Then the logo is cut out and then stuck on the kite. The stickers typically stick very well however we cannot guarantee them for the life of the kite.
If the logo is not too complicated we can cut into the sail as its single surface (or both surfaces of foil kites). The logos look amazing and the light shines through beautifully. Price depends on the size and how complicated the logo is. Please note that we can only use our standard colour fabrics. Ask your local distributor for feasibility.
